from pathlib import Path
import os
from collections import defaultdict

from IPython.display import HTML, Image
import numpy as np
import matplotlib.pyplot as plt
from celluloid import Camera
import torch.optim as optim
import torch

ROOT = Path("./assets/img/")

if not os.path.exists(ROOT):
    os.makedirs(ROOT)

def get_dummy_optimizer(lr):
    return optim.SGD([torch.tensor(0)], lr=lr)

def step_lr():

    optimizer = get_dummy_optimizer(lr=1.)
    scheduler = optim.lr_scheduler.StepLR(optimizer, step_size=50, gamma=0.1)

    epochs = np.arange(0, 200)

    lr_arr = []
    for epoch in epochs:
        lr = scheduler.get_last_lr()
        lr_arr.append(lr)

        optimizer.step()
        scheduler.step()

    lr_arr = np.array(lr_arr)

    fig, (ax, ax_log) = plt.subplots(1, 2, figsize=(12,5))

    fig.suptitle("StepLR")

    ax.set_xlabel("epoch")
    ax.set_ylabel("lr")

    ax_log.set_xlabel("epoch")
    ax_log.set_ylabel("lr (log-scale)")

    ax_log.set_yscale("log")

    camera = Camera(fig)
    for epoch in epochs:
        ax.scatter(epoch, lr_arr[epoch], color="royalblue")
        ax.plot(epochs[:epoch+1], lr_arr[:epoch+1], color="royalblue")

        ax_log.scatter(epoch, lr_arr[epoch], color="royalblue")
        ax_log.plot(epochs[:epoch+1], lr_arr[:epoch+1], color="royalblue")

        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "steplr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

step_lr()

def exp_lr():

    epochs = np.arange(0, 200)
    gammas = [0.9, 0.95, 0.99]

    lr_dict = defaultdict(list)
    for gamma in gammas:

        optimizer = get_dummy_optimizer(lr=1.)
        scheduler = optim.lr_scheduler.ExponentialLR(optimizer, gamma=gamma)

        for epoch in epochs:
            lr = scheduler.get_last_lr()
            lr_dict[gamma].append(lr)

            optimizer.step()
            scheduler.step()

    fig, (ax, ax_log) = plt.subplots(1, 2, figsize=(12,5))

    fig.suptitle("ExponentialLR")

    ax.set_xlabel("epoch")
    ax.set_ylabel("lr")

    ax_log.set_xlabel("epoch")
    ax_log.set_ylabel("lr (log-scale)")

    ax_log.set_yscale("log")

    colors = {
        0.9: "royalblue",
        0.95: "orangered",
        0.99: "forestgreen",
    }

    camera = Camera(fig)
    for epoch in epochs:

        lines = []
        log_lines = []

        for gamma in lr_dict.keys():

            lr_arr = np.array(lr_dict[gamma])

            ax.scatter(epoch, lr_arr[epoch], color=colors[gamma])
            line, = ax.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color=colors[gamma], label=r"$\gamma=%s$" % gamma)


            ax_log.scatter(epoch, lr_arr[epoch], color=colors[gamma])
            log_line, = ax_log.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color=colors[gamma], label=r"$\gamma=%s$" % gamma)

            lines.append(line)
            log_lines.append(log_line)

        ax.legend(handles=lines)
        ax_log.legend(handles=log_lines)

        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "explr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

exp_lr()

def poly_lr():

    epochs = np.arange(0, 200)
    powers = [1., 2., 3., 4., 5.]

    lr_dict = defaultdict(list)
    for power in powers:

        optimizer = get_dummy_optimizer(lr=1.)
        scheduler = optim.lr_scheduler.PolynomialLR(optimizer, power=power,
                                                    total_iters=150)

        for epoch in epochs:
            lr = scheduler.get_last_lr()
            lr_dict[power].append(lr)

            optimizer.step()
            scheduler.step()

    fig, ax = plt.subplots(1, 1, figsize=(5,5))

    fig.suptitle("PolynomialLR")

    ax.set_xlabel("epoch")
    ax.set_ylabel("lr")

    colors = {
        1.: "royalblue",
        2.: "orangered",
        3.: "forestgreen",
        4.: "mediumblue",
        5.: "crimson",
    }

    camera = Camera(fig)
    for epoch in epochs:

        lines = []

        for power in lr_dict.keys():

            lr_arr = np.array(lr_dict[power])

            ax.scatter(epoch, lr_arr[epoch], color=colors[power])
            line, = ax.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color=colors[power], label=f"power={power}")


            lines.append(line)

        ax.legend(handles=lines)

        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "polylr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

poly_lr()

def cyclic_lr():

    base_lr = 0.1
    max_lr = 1.

    modes = ["triangular", "triangular2", "exp_range"]

    epochs = np.arange(0, 200)

    fig, axes = plt.subplots(1, 3, figsize=(18,5))

    lr_dict = defaultdict(list)

    for mode in ["triangular", "triangular2"]:

        optimizer = get_dummy_optimizer(lr=1.)
        scheduler = optim.lr_scheduler.CyclicLR(optimizer, mode=mode,
                                                step_size_up=50, base_lr=base_lr, max_lr=max_lr)

        for epoch in epochs:

            lr = scheduler.get_last_lr()
            lr_dict[mode].append(lr)

            optimizer.step()
            scheduler.step()


    mode = "exp_range"
    gammas = [0.99, 0.98, 0.97]
    lr_exp_range_dict = defaultdict(list)

    for gamma in gammas:
        optimizer = get_dummy_optimizer(lr=1.)
        scheduler = optim.lr_scheduler.CyclicLR(optimizer, mode=mode, gamma=gamma,
                                                step_size_up=50,
                                                base_lr=base_lr, max_lr=max_lr)

        for epoch in epochs:

            lr = scheduler.get_last_lr()
            lr_exp_range_dict[gamma].append(lr)

            optimizer.step()
            scheduler.step()

    fig.suptitle("CyclicLR")

    for idx, ax in enumerate(axes):
        ax.set_xlabel("epoch")
        ax.set_ylabel("lr")

        mode = modes[idx]
        ax.set_title(mode)

    exp_range_colors = {
        0.99: "royalblue",
        0.98: "orangered",
        0.97: "forestgreen",
    }

    camera = Camera(fig)

    for epoch in epochs:
        for idx, mode in enumerate(["triangular", "triangular2"]):
            ax = axes[idx]

            lr_arr = np.array(lr_dict[mode])

            ax.scatter(epoch, lr_arr[epoch], color="royalblue")
            ax.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color="royalblue")

        ax = axes[2]
        lines = []
        for gamma in gammas:
            color = exp_range_colors[gamma]

            lr_arr = np.array(lr_exp_range_dict[gamma])

            ax.scatter(epoch, lr_arr[epoch], color=color)
            line,  = ax.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color=color, label=r"$\gamma=%s$" % gamma)

            lines.append(line)

        ax.legend(handles=lines)
        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "cycliclr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

cyclic_lr()

def onecycle_lr():

    max_lr = 1.

    max_epochs = 200
    epochs = np.arange(0, max_epochs)

    fig, axes = plt.subplots(1, 1, figsize=(5,5))

    lr_dict = defaultdict(list)

    for threephase in [True, False]:

        optimizer = get_dummy_optimizer(lr=1.)
        scheduler = optim.lr_scheduler.OneCycleLR(optimizer, max_lr=max_lr, total_steps=max_epochs,
                                                  three_phase=threephase,)

        for epoch in epochs:

            lr = scheduler.get_last_lr()
            lr_dict[threephase].append(lr)

            optimizer.step()
            scheduler.step()

    fig.suptitle("OneCycleLR")

    axes.set_xlabel("epoch")
    axes.set_ylabel("lr")

    camera = Camera(fig)

    colors = {
        True: 'royalblue',
        False: 'orangered',
    }

    for epoch in epochs:

        lines = []
        for threephase in [True, False]:

            lr_arr = np.array(lr_dict[threephase])

            color = colors[threephase]
            axes.scatter(epoch, lr_arr[epoch], color=color)
            line, = axes.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                            color=color, label=("three_phase" if threephase else "two_phase"))

            lines.append(line)

        axes.legend(handles=lines)

        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "onecyclelr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

onecycle_lr()

def cosanneal_lr():

    max_epochs = 200
    epochs = np.arange(0, max_epochs)

    fig, axes = plt.subplots(1, 1, figsize=(5,5))

    lr_arr = []

    optimizer = get_dummy_optimizer(lr=1.)
    scheduler = optim.lr_scheduler.CosineAnnealingLR(optimizer, T_max=max_epochs)

    for epoch in epochs:

        lr = scheduler.get_last_lr()
        lr_arr.append(lr)

        optimizer.step()
        scheduler.step()

    lr_arr = np.array(lr_arr)

    fig.suptitle("CosineAnnealingLR")

    axes.set_xlabel("epoch")
    axes.set_ylabel("lr")

    camera = Camera(fig)

    color = "royalblue"

    for epoch in epochs:

        axes.scatter(epoch, lr_arr[epoch], color=color)
        line, = axes.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                        color=color,)


        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "cosanneallr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

cosanneal_lr()

def coswarm_lr():

    max_epochs = 200
    epochs = np.arange(0, max_epochs)

    T_0 = 50
    T_mult = 3

    fig, axes = plt.subplots(1, 1, figsize=(5,5))

    lr_arr = []

    optimizer = get_dummy_optimizer(lr=1.)
    scheduler = optim.lr_scheduler.CosineAnnealingWarmRestarts(optimizer, T_0=T_0, T_mult=T_mult)

    for epoch in epochs:

        lr = scheduler.get_last_lr()
        lr_arr.append(lr)

        optimizer.step()
        scheduler.step()

    lr_arr = np.array(lr_arr)

    fig.suptitle("CosineAnnealingWarmRestarts")

    axes.set_xlabel("epoch")
    axes.set_ylabel("lr")

    camera = Camera(fig)

    color = "royalblue"

    for epoch in epochs:

        axes.scatter(epoch, lr_arr[epoch], color=color)
        line, = axes.plot(epochs[:epoch+1], lr_arr[:epoch+1],
                        color=color,)


        camera.snap()

    anim = camera.animate()
    plt.close()

    gif_path = ROOT / "coswarmlr.gif"
    anim.save(gif_path, writer="pillow", fps=30)
    return Image(url=gif_path)

coswarm_lr()
